C.L.T – Cross Lam Timber

cross lam timber 2

CLT “Cross Laminated Timber” is a solid, static load-bearing timber panel that is ideal for many structural requirements thanks to its flexible dimensions and outstanding physical properties.

cross lam timber

Durable bonding of the cross-wise layered construction made of high-quality raw material guarantees that the components are absolutely dimensionally stable and rigid.

As a building product, its versatile nature and multi-use qualities are leading the way in forward thinking design where traditionally other materials were used.

What’s it made from?

Finger-jointed and planed lamellas of graded Spruce wood from sustainably managed forests are laid next to each other and the flat surfaces of the layers glued at right angles to one another. To avoid uncontrolled stress cracks, the narrow sides are not glued. The layers are pushed laterally to dimension before applying the pressure (1.2 N/mm2) in order to obtain a gap-free surface.

The manufactured panels are then surface planned to exacting sizes. The panels can be supplied either as ‘blank’ CLT panels or can be CNC fabricated to allow for rebates, drill holes & connection details etc all as per the project requirements.

cedarlan cork cross lam timber

What we provide:

Structural design, manufacture of the CLT panels using the latest 3D CAD modeling and panel processing, delivery and fitting.

Advantages:

  • Solid, value-maintaining construction

  • Space gain due to reduced component thickness

  • Larger / higher construction over timber frame

  • Flexible design without grid pattern

  • Excellent shape and dimensional accuracy

  • Outstanding structural properties

  • Prefabricated elements, simple low-dust and low-noise assembly

  • Short building time due to dry construction

  • Natural, sustainable construction material

  • CO2 reservoir
